Hi-Target HTS-420R User Manual

Total Station Manual
- 144 -
1.3 Delete a job
Steps
Key
Display
○
1 In the menu of Job
Manager, press [F1] to enter
the menu of job function.
[F1]
[Job Manage] 1/2
F1 F2 F3 F4
F1 Job (1)
F2 Fix Pt. (2)
F3 Meas. PT (3)
F4 Code (4)
○
2 The interface displays the
job list in the current storage.
The jobs in the SD card have
the mark of “[SD]” and the
current job have the mark of
“*”.
Delete
New View OK
[Job list]
JOB1 *
JOB2
JOB3 [SD]
JOB4 [SD]
○3 Using the direction key up
or down to select the job that
need to be deleted. Press [F1]
(Delete) and a dialog appears
as shown in the picture on the
right.
If you make sure to delete it,
please press [F4] (Yes),
otherwise, press [F1] (No) to
back to the previous menu.
※
1
[↑]、
[↓]
+
[F1]
+
[F4]
Sure to delete job?
Data cannot recover!
No Yes
※
1
：The current job can’t be deleted.
