2.4 EDM signal
The function of signal is to display the intensity of signal received by total
station.If the target is hard to be found or can’t see, using the function can achieve
the best sighting accuracy.
Steps
Key
Display
○
1 After entering to the
interface of EDM Setting,press
the key of [F4] to enter the
second page of soft key, then
press te key of [F2](Signal)
to enter the function of Signal
intensity.
[F4]
+
[F2]
[EDM Setting]
EDM Mode:
Reflector:
P.C. :
Grid Signal
Single
Prism
30.0 mm
○
2 Using the bar chart and
value of number to show the
intensity of signal received by
total station in the screen. As
shown in the picture on the
right.
[EDM Signal]
Strength:
Back
50
○
3 Press [F1] or [ESC] to back
to the menu of EDM setting.
[F1]
or
[ESC]
[EDM Setting]
EDM Mode:
Reflector:
P.C. :
Grid Signal
Single
Prism
30.0 mm
