9.7 Message Reference
140
(8) Reading Measured Values
Set and query the Trigger Delay 1 time
Syntax
Command
:TRIGger:DELay1 <Delay1 time>
Query
Response
:TRIGger:DELay1?
<Delay1>
<Delay1 time> = 0 to 0.100 (NR2) (seconds)
Example
:TRIG:DEL1?
0.010
Set and Query the Trigger Signal Logic
Syntax
Command
:TRIGger:EDGE <RISE/ FALL>
Query
Response
:TRIGger:EDGE?
<RISE/ FALL>
<RISE> = Rising (OFF) edge
<FALL> = Falling (ON) edge
Description
Set the operating logic of the TRIG signal at external I/O pins.
Example
:TRIG:EDGE?
FALL
Measurement Value Formats
Note
For positive measured values, a space (ASCII 20H) represents the sign.
Measurement
Range
Measured Value ±OvrRng Measurement Fault
100m ±
.E-3 ±100.0000E+7 +100.0000E+8
1000m ±.E-3 ±1000.000E+6 +1000.000E+7
10 ±
.E+0 ±10.00000E+8 +10.00000E+9
100 ±.E+0 ±100.0000E+7 +100.0000E+8
1000 ±
.E+0 ±1000.000E+6 +1000.000E+7
10k ±.E+3 ±10.00000E+8 +10.00000E+9
100k ±
.E+3 ±100.0000E+7 +100.0000E+8
1000k ±.E+3 ±1000.000E+6 +1000.000E+7
10M ±
.E+6 ±10.00000E+8 +10.00000E+9
100M ±.E+6 ±100.0000E+7 +100.0000E+8
