Chapter 10 Specifications
178
Accessories
Options
Power source Rated supply voltage 100 to 240 VAC (Voltage fluctuations of ±10% from the rated sup-
ply voltage are taken into account)
Rated supply frequency: 50/60 Hz
Anticipated transient overvoltage 2,500 V
Maximum rated power 30 VA
Dimensions Approx. 260W x 88H x 300D mm (10.24"W × 3.46"H × 11.81"D)
Mass Approx. 2.9 kg (102.3 oz.)
• Power Cord (2-line + ground) (1)
• EXT I/O Male Connector (1)
• Instruction Manual (This document) (1)
• Operation Guide (1)
• Model 9140 4-terminal Probe
• Model 9262 Test Fixture (less than 10 m residual resistance after zero adjustment)
• Model 9263 SMD Test Fixture (less than 10 m residual resistance after zero adjustment)
Interface Cables:
• Model 9637 RS-232C Cable (9-pin to 9-pin/ crossover cable)
• Model 9638 RS-232C Cable (9-pin to 25-pin/ crossover cable)
• Model 9151-02 GP-IB Connector Cable (2 m)
