Rear swing arm assy.

CHECKING Rear Swing arm

1. Check:

• rear swing arm assy.

Damage/pitting

Replace

2. Check:

• rear shock absorber parts

Bends/damage

Replace.

3. Check:

• Rear swing arm bushing

Wear/damage

Replace.
