Affirm Breast Biopsy Guidance System User Guide
Chapter 3: Installation, Verification, and Removal
MAN-06411-002 Revision 003 Page 23
The Lateral Arm can be mounted to the left or the right side of the Biopsy Guidance
Module to permit a lateral needle approach from either direction. Determine the desired
approach before mounting the Lateral Arm and install the Biopsy Control Module on the
opposite side from the desired approach.
Figure 14: Left Needle Approach of Lateral Arm (Blue)
Figure 15: Right Needle Approach of Lateral Arm (Yellow)
