Affirm Breast Biopsy Guidance System User Guide
Chapter 5: Biopsy
Page 60 MAN-06411-002 Revision 003
Figure Legend
1. Create Target assigns target point(s) and creates a target icon in the target set (item
10). After you assign your target, click the button a second time to accept the target
and transfer the target coordinates to the Biopsy Control Module.
2. Reject Target removes the selected target from the list of target icons if that target
was not yet accepted.
3. Resend Target resends the selected target coordinates to the Biopsy Control Module.
4. Project Target shows the selected target on an additional stereo pair on the Preview
screen.
5. Delete Target deletes the selected target from the list of target icons if that target was
accepted.
6. Move Z-Target Up moves the final position of the needle away from the Breast
Platform and the graphic of the lesion downward. The values for the safety margins
change accordingly.
7. Move Z-Target Down moves the final position of the needle toward the Breast
Platform and the graphic of the lesion upward. The values for the safety margins
change accordingly.
8. Show/Hide Targets shows/hides all target icons in the list of targets.
9. Device shows the name of the attached biopsy device that was selected from the
related drop-down list.
Warning:
Patient injury can occur if the device you select in the Biopsy tab is not the
device that is installed on the system.
Note
If your biopsy device does not show in the drop-down menu, contact Technical
Support. A Service Engineer must enter the device specifications.
