USER INTERFACE
6.6 ThinPrep™ 5000 Processor with AutoLoader Operator’s Manual
6
Slides
Figure 6-4 Slides Pane on Main Screen
The slides pane shows how the slide cassettes are configured by type and indicates whether the
cassettes are full or not. Touch the
Slides button or anywhere on the slides pane to display the Slide
Details screen (Figure 6-5).
Figure 6-5 Slide Details Display
Touch the Slides button or anywhere on the pane to open
the Slides Details display.
Cassette 1 is selected as Gyn type slide and it is partially
full
Cassette 2 is selected as Non-Gyn type slide and it is full
Cassette 3 is selected as UroCyte type slide and it is empty
Grayed out:
Cassettes 2 and 3 have been selected as Gyn type, but the
cassette is not present
Slide door closed Slide door open
Press the button to select the type of slide
in the cassette.
Press the Done button to return to the main
screen
The cassette number
corresponds with the
position it is in when
placed in the instrument
