MAINTENANCE
8.18
ThinPrep™ 5000 Processor with AutoLoader Operator’s Manual
CHANGE FUME EXTRACTOR FILTERS
The fume extractor for the laser etcher has a HEPA filter and a carbon filter to capture particulate
matter and gas and odor. The fume extraction cabin is located inside the waste cabinet door. (See
Figure 8-20.)
The instrument will prompt the user if the HEPA filter needs to be changed. The carbon filter may be
changed on a yearly basis or more often, as desired.
Figure 8-19 Change HEPA Filter Message
Note:
Do not press the
Continue
button until the filter has been changed.
Change HEPA filter message.
This message is seen when
prompted by the instrument or
when the
Change Air Filter
but-
ton is pressed on the Admin
Options screen.
