ThinPrep™ 5000 Processor with AutoLoader Operator’s Manual 1.11
1
INTRODUCTION
TECHNICAL SPECIFICATIONS
Overview of Components
Figure 1-4 Overview of Components
SECTION
B
Slide cassettes (3)
Sample vial tray bays
(4)
Vial door 1
Vial door 2
Vial door 3
Vial door 4
ThinPrep filter tray
bays (3)
ThinPrep
™
5000 Processor with AutoLoader
Processor
User interface
Carousel
Baths door
Filter waste bin
Liquid waste bottle
and slide waste bin
(behind door)
Laser fume extractor
filters
Main door (input door)
Slide transport arm
Filter/vial transport arm
Filter plug
Vial gripper
Fixative bath evaporative
cover
Touch screen
Baths door
ThinPrep 5000 processor
Laser slide etcher
(not in view)
Robot housing with
AutoLoader slide gripper on
robot arm
