ThinPrep™ 5000 Processor with AutoLoader Operator’s Manual 1.13
1
INTRODUCTION
Environmental
Operating temperature
16–32°C
60–90°F
Operating humidity
20%–80% RH, non-condensing
Non-operating temperature
-28°C–50°C
-20°F–122°F
Non-operating humidity
15%–95% RH, non-condensing
Sound levels
Below 85 dBA maximum at normal operator’s position
Heat load
Maximum 529 watts = 1805 BTU/hr or 1904 Joule/hr
Power
Electrical Voltage & frequency power
100–120 V, ~6A, 50/60 Hz
220–240V, ~2A, 50/60 Hz
Fusing
Two 6.3A/250V 5x20 mm SLO-BLO
Laser
Type: CW CO
2
infrared
Wavelength: 10,600 nm
Rated Power: 10W max
Connections to External Circuits
The external connections on the ThinPrep
™
5000 processor with AutoLoader are PELV (Pro-
tected Extra Low Voltage) as defined by IEC 61140. Outputs of other devices connected to the
instrument should also be PELV or SELV (Separated Extra Low Voltage). Only devices
