Honeywell MPA2C3 User Manual

MPA2C3 User Manual 133
Panel Resets and Restorations
DIP Switch Settings
MPA2C3 SW1 DIP Switch Settings.
1. DIP Switch SW1 bit 4 does NOT require a panel reboot to take effect. This does
not affect the USB2 - WEB MODE IP address.
Note: A Primary panel (SW1 bit 3 ON) cannot be set to address 31.
S1 S2 S3 S4 S5 S6 S7 S8 S9 S10 Selection
OFF OFF ON OFF OFF OFF OFF OFF ON OFF Factory Settings
OFF Reader 1 and Reader 3 = Wiegand
ON Reader 1 and Reader 3 = OSDP (OSDP 1)
OFF Future Use - set to OFF
OFF Downstream/Secondary Panel
ON Master/Primary Panel
OFF Uses the User Provided Ethernet IP Address
ON Uses the Default IP Address(192.168.1.15
0)
OFF OFF OFF OFF ON Address 1
OFF OFF OFF ON OFF Address 2
OFF OFF OFF ON ON Address 3
OFF OFF ON OFF OFF Address 4
OFF OFF ON OFF ON Address 5
OFF OFF ON ON OFF Address 6
OFF OFF ON ON ON Address 7
OFF ON OFF OFF OFF Address 8
OFF ON OFF OFF ON Address 9
OFF ON OFF ON OFF Address 10
OFF ON OFF ON ON Address 11
OFF ON ON OFF OFF Address 12
OFF ON ON OFF ON Address 13
OFFONONONOFF Address 14
OFFONONONON Address 15
ON OFF OFF OFF OFF Address 16
ON OFF OFF OFF ON Address 17
ON OFF OFF ON OFF Addr
ess 18
ON OFF OFF ON ON Address 19
ON OFF ON OFF OFF Address 20
ON OFF ON OFF ON Address 21
ON OFF ON ON OFF Address 22
ONOFFONONON Address 23
ON ON OFF OFF OFF Address 24
ON ON OFF OFF ON Address 25
ON ON OFF ON OFF Address 26
ON ON OFF ON ON Address 27
ON ON ON OFF OFF Address 28
ON ON ON OFF ON Address 29
ON ON ON ON OFF Address 30
ON ON ON ON ON Address 31*
OFF Reader 2 and Reader 4 = Wiegand
ON Reader 2 and Reader 4 = OSDP (OSDP 2)
