MPA2C3 User Manual 63
4. Configure Shunt and Debounce times.
5. Configure Scheduling.
6. Click Save.
Configuring Door Outputs
The Outputs tab allows you to configure the following settings:
1. Discrete or Group selection
2. Output Name and Pulse Duration
3. Latch and Interlocks
4. Special output modes controlled by cards
Table 2-7
Configura-
tion
Description
Shunt Time
(h:m:s)
Specifies the amount of time for which the inputs
are shunted, or de-activated. The maximum length
of time is 1 hour, 45 minutes, 59 seconds.
You can express seconds in tenths of a second.
Debounce
Time (h:m:s)
Specifies the period of time (MIN = 0 second, MAX =
6553.5 seconds) the input must remain in a new
state before generating an alarm. For example, with
a 5-second debounce time selected, if a Normal
state is changed to Alarm, the state must remain in
Alarm for five consecutive seconds before an alarm
is generated.
Table 2-1
Configuration Description
Shunt Specifies the time period during which the input will
be ignored.
Disable
Interlocks
Specifies the time period during which the pro-
grammed action on this input from another point
will be disabled.
Disable
Alarm Mes-
sages
Specifies the time period during which Alarm and
Normal will not be reported, but Short and Cut will
be reported. Short alarms are triggered when a
short occurs in the input cable. Cut alarms are trig-
gered when a wire is cut.
To Next Page
