HP 8114A Service Guide
Refitting the Motherboard
Refitting the motherboard is the reverse procedure of removal. Please
not,e
the following:
Note
Before finally tightening the 7 screws, which secure the motherboard
t,o
the chassis, it is recommended to first, connect the microprocessor
board, and the timing board to the motherboard to align the
connections, and then tighten the screws.
Remember to fit the
RF1
Shield, Part No.
8160-0662
between the
37.pin
D
connector and the chassis.
Disassembly and Reassembly
4-19
