Test 6: Amplitude
Test Specifications
Range:
Equipment Needed
The following tests are required:
1. From 500 into 500
2. From HIZ (lhgh-Z) into 500
A) 1.00 V to 50.0 V (500 into 508)
B) 2.00 V to 100 V (HIZ (High-Z} into 5061)
Accuracy: kl % of amplitude 5100 mV
Resolution: 3 digits, best case 10 mV
Baseline: 0 V &lo0 mV ;tO.5% of amplitude
1. Digitizing Voltmeter (DVM)
2. High Power attenuator
3. 5061, O.l%, 10 W Feedthrough
Calculating out Measurement Uncertainties
Measurement uncertainties need to be calculated out as follows:
a) For 5061 into 5061 measurements, the Attenuation Factor must be
calculated
b) For HIZ (High-Z) into 5061 measurements, the Attenuation Factor,
Load impedance, and Adjust factor must be calculated.
Do these calculations as follows:
Testing the HP 6114A 3-25
