HP 8114A Service Manual

Test 9: Pulse Aberration Test
‘The following tests arc required:
1) Overshoot and Ringing
2) Preshoot
Test Specifications
Overshoot/Ringing/Preshoot:
55% of amplitude 150 mV
Equipment Needed
Digitizing Oscilloscope with Accessories
High Power Attenuator
Procedure
1. Connect HP 8114A to the Scope as shown:
HP 8! ’ 4A UNDER TEST
HP 5412 IT FRONT-END
Connecting HP 8114A to the Scope
On the HP 8114A press TRIGGER and set up page as follows:
n il:~:ii$- I W:IIJ; Pl_lL!:E:;
n si!-,sgi;j plJlscs
2. On the HP 8114A set up the !XJTPUT page as shown in the
following illustration:
Per 1.00w out ON
Inh OFF f
(OM001FYI
Delay 0.00ns Baselne +0.00v
Dut yCyc 50.0 % kplitd -U
50R into 50.0 R -JX.
Configuring the Output Page
Testing the HP 8114A 341
