HP 8114A Service Manual

HP 8114A Specifications
Pulse Timing
Period
Measured at 50% of amplitude
Repeatability:
factor 4 better than accuracy
Can be set as period or frequency
Range:
66.7 ns to 999 ms (Frequency: 1.00 Hz to 15.0 MHz)
Accuracy:
33% zt100 ps
Resolution:
3 digits, best case 100 ps
RMS-Jitter:
0.03% + 25 ps (0.05% + 25 ps in the 66.7 ns to 100 ns range)
Width
Can be set as width, duty-cycle or trailing-edge delay.
Range
10 ns to 150 ms
Accuracy:
zt5% 1500 ps
Resolution:
3 digits, best case 100 ps
RMS-Jitter:
0.03% + 25 ps (0.05% + 25 ps in the 50 ns to 100 ns range)
2-6 HP 6114A Pulse Generetor

HP 8114A Specifications
