HP 8114A Service Guide
5. Front Panel Legend Foil
Caution
Take great care when attaching a new foil. If you misalign the foil,
you may not be able
t,o
re-attach it after removal, as it is extremely
likely to be damaged in the process. If you damage the foil you will
need another new one.
a. Lay the new foil with its protective backing in place, on
t,op
of
the Front Panel frame, in the correct position
b.
IJsing
adhesive tape, secure the foil in position for just less than
half its length
c. Raise the free end of the foil and peel off a half section of the
protective backing sheet
d. Carefully lower the free end of the foil to the Front Panel
frame and smooth it into firm contact. Avoid the inclusion of
air-bubbles by smoothing the foil from the centre toward the
end of the Front Panel frame. The adhesive is immediately
effective and the foil cannot now be moved.
e. Remove the adhesive tape and the remaining half of the foil
protective backing sheet and smooth the foil into contact with
the other half of the Front Panel frame
Replacing or Refitting the. Motherboard
Replacing or refitting the Motherboard is the reverse of removing, but
it is important to remember to fit the
RF1
Shield, Part No. 8160-0562
between the 37-pin D connector and the chassis sub front panel.
Disassembly and Reassembly 4-27
