HP 8114A Service Manual

Test 8.2a: Leading Edge Test
Leading edge for amplitudes >lO V from HIZ (High-Z) into 5OQ.
Procedure
1. Connect HP 8114A to the Scope as shown:
I
I!
1
M TYPE TO ENCADAPTOR
Connecting HP 8114A to the Scope
On the HP 8114A press TRIGGER and set up page as follows:
m r::C+IT 1 ~~~lJ:il~!~; F;i_lL!:;ES
n if;j.rj:gi,!a F~~lses
2. On the HP 8114A set-up the OUTPUT page as shown in the
following illustration:
Configuring the Output Page
Testing the HP 9114A 3-39
