141
Appendix A. Installation and Maintenance
Operating and Storage Environment
Storage Position
The HP 8164A Lightwave Measurement System can be stored in its
operating position, as shown in Figure A-5, or on its back legs as
shown in Figure A-7. The back legs protect the connectors on the
back panel from damage.
CAUTION Before positioning the HP 8164A Lightwave Measurement System on
its back legs:
• make sure that the instrument is in stand-by mode, see page 76 and
• disconnect all connections to the back panel.
