Appendix A. Installation and Maintenance
Using Modules
How to Fit a Back-Loadable Module
CAUTION Disconnect all electrical and optical connectors before you fit this
module into the instrument, as this can cause damage to the
connectors.
Make sure that the instrument is in stand-by mode, see page 135,
before you remove a module.
1 Position the module at the rear of the instrument as shown in
Figure A-14.
2 Insert the module into the mainframe, using the handle, being
Figure A-14 Fitting a Back-Loadable Module
Tighten Retaining Screws
Insert module
along the direction shown
by this arrow
