Appendix A. Installation and Maintenance
Using Modules
CAUTION Ifyoupull the module out at an angle or vertically, you may damage the
instrument and the module. You should pull the module out along the
direction shown by the arrow in Figure A-13.
Figure A-13 Removing a Back-Loadable Module from the HP 8164A
Untighten Retaining Screws
Remove module by pulling
along the direction shown
by this arrow
