134
Appendix A. Installation and Maintenance
AC Line Power Supply Requirements
WARNING To avoid hazardous electrical shock, do not perform electrical tests
when there are signs of shipping damage to any portion of the outer
enclosure (covers, panels, and so on).
A.3 AC Line Power Supply Requirements
The HP 8163A Lightwave Multimeter can operate from the single-
phase AC power source that supplies between 100 V and 240 V at a
frequency in the range 50 to 60 Hz. The maximum power
consumption is 120 VA with all options installed.
The HP 8164A Lightwave Measurement System can operate from
any single-phase AC power source that supplies between 100 V and
240 V at a frequency in the range from 50 to 60 Hz. The maximum
power consumption is 270 VA with all options installed.
Line Power Cable
In accordance with international safety standards, the instrument
has a three-wire power cable. When connected to an appropriate
AC power receptacle, this cable earths the instrument cabinet.
