Appendix C. Specifications
HP 8163A Specifications
C.1 HP 8163A Specifications
The HP 8163A Lightwave Multimeter has a dual channel display.
Display
Graphical display 190 × 300 points visible,
monochrome.
Compatibility with HP 8153A
Lightwave Multimeter Modules
The HP 8163A mainframe supports all modules
from the HP 8153A Lightwave Multimeter, apart
from the HP 81534A Return Loss Module .
Data Acquisitions
Memory>
Sampling time
Selectable data averaging time
Selectable total data averaging time
4000 measurement results / channel
min 100 µs or 10 ms, depending on sensor module
20 ms to 60 min
20 ms to 99:59:59 h
Trigger
True synchronous on all channels
Environmental
Storage temperature
Operating temperature
Humidity
−40°C to +70°C
0°C to +45°C
<95% R.H. from 0°C to +45°C
Power
AC 100 - 240 V ± 10%, 48 - 66 kHz, 100 VA max.
Dimensions
88 mm × 213 mm × 380 mm
(3.5" × 8.4" × 15")
Weight
net 4.200 kg (9.3 lbs); shipping 6.5 kg (14.5 lbs)
HP-IB interface
Function code
HP-IB capability
SH1, AH1, T6, L4, SR1, RL1, PP0, DC2, DT0, C0.
SCPI standard; HP 8153A code compatibility
All modes and parameters accessible via HP-IB
interface
