170
Appendix C. Specifications
HP 8164A Specifications.
C.2 HP 8164A Specifications.
RS232C Interface: max. baud rate
115200 bps
Parallel Printer Interface
Centronics
Number of Modules
2 Modules
Display
600 × 400 pixels visible, active colour LCD.
VGA connector for external monitor.
Compatibility with HP 8153A
Lightwave Multimeter Modules
The HP 8164A mainframe supports all modules
from the HP 8153A Lightwave Multimeter, apart
from the HP 81534A Return Loss Module .
Data Acquisitions
Memory
Sampling time
Selectable data averaging time
Selectable total data averaging time
4000 measurement results / channel
min 100 µs or 10 ms, depending on sensor module
20 ms to 60 min
20 ms to 99:59:59 h
Trigger
True synchronous on all channels
Environmental
Storage temperature
Operating temperature
Humidity
−40° C to 70° C
10° C to 35° C
< 80% R.H. from 10° C to 35° C
Power
100 to 240 Vrms, ± 10%, 280 VA max.
Dimensions
145 mm × 426 mm × 545 mm
(5.8" × 16.9" × 21.6")
