28
Getting Started
The HP 8164A Lightwave Measurement System
The HP 8163A Lightwave Multimeter mainframe has two slim
module slots. The system can host up to two front-loadable
modules, of any combination of the following types:
• the HP 81689A Tunable Laser,
• Power Sensors,
• fixed wavelength Laser Sources, and
• Interface Modules for Optical Heads.
The front-loadable module slots support all modules designed for
the HP 8153A Lightwave Multimeter except the HP 81534A
Return Loss Module, which may be supported by later firmware
releases.
1.2 The HP 8164A Lightwave Measurement
System
The HP 8164A Lightwave Measurement System mainframe has
one large and four slim module slots.
Figure 1-2 The HP 8164A Lightwave Measurement System Mainframe
