Rail Kits

The following items are included in the rail kits:

Rail Kits

Right and left 2U rail subassembly (right subassembly shown)

Right and left 4U rail subassembly (right subassembly shown)

M5 screw for middle support bracketM5 shoulder screw for rack mount

M5 cage nutMiddle support bracket

Rail Kits 119
