WARNING!
To reduce the risk of fire, electric shock and damage to power sources.
• Connect only to a circuit providing branch circuit overcurrent protection of appropriate current
rating.
• Connect the input power cord into a grounded (earthed) electrical outlet that is located near
the equipment and is easily accessible.
• Be sure all circuit breakers are in the off position before connecting input power.
• Be sure that the load products connected to the HPE PDU are adjusted for, or otherwise
capable of operation from the same line voltage supplying the PDU. Failure to verify the
voltage can lead to severe equipment damage.
• Do not overload the PDU. The total input current rating of all equipment connected to each
output cannot exceed the total output rating marked on the PDU.
• Use only the hardware provided to install the PDU.
Required Tools
The following tools are required for PDU installation:
• Phillips screwdriver
• Torx screwdriver
NOTE: If your facility or configuration requires an L5–20R plug, you must obtain a third-party
L5–20R to NEMA 5–20P adapter before installing or connecting the HPE 1.9kVA 120V Basic
PDU ( H5M54A).
Required Tools 43
