Node LEDs
Figure 17 Node LEDs location
Table 16 Node LEDs description
IndicatesStateAppearanceFunctionLED Icon
Not a Cluster memberOnGreenStatus
BootRapid Flashing
Cluster memberSlow Flashing
Locate active and safe to removeSolid BlueBlueUID/Service
Locate active but not safe to remove
Flashing Blue
The locatenode command used to
flash the UID LED.
Locate not activeOff
FaultOnAmberFault
No faultOff
Node in cluster and faultFlashing
Controller Nodes 27
