Service Processor Installation
The physical SP consists of the following:
• 3PAR Service Processor
• 1U Mounting Kit (PN 734806-B21)
NOTE: The SP ID is the HPE 3PAR StoreServ Storage array 10-digit serial number preceded
by the letters "SP". For example, if the storage array serial number is 0001614983, the SP ID is
SP0001614983. The SP ID is the Hewlett Packard Enterprise 10-digit serial number. Legacy
3PAR StoreServ Storage systems used 7-digit serial numbers for configuration. The 3PAR
StoreServ 8000 Storage no longer has a 7-digit serial number, but uses instead a 10-character
serial number for configuration.
This requires up-to-date versions of HPE 3PAR SP and VSP software and of HPE 3PAR
SmartStart.
The 3PAR StoreServ Storage system serial number can be obtained from the following:
• Located at the rear of the system next to the power switch for the controller node enclosure
PCM.
• Located in the product documentation provided with your system.
The following components are included in the SP 1U mounting kit:
• Slide mounting rail
• Screws
• Cage nuts (for the round-hole rack)
• Cable management straps
• Labels
In addition to the supplied items, you might also need the following:
• Screws fitting a threaded-hole rack
• Screwdriver
• Optional cable management arm (see Figure 72 (page 73))
72 System Component Installation in Existing Rack
