Drive LEDs
Figure 20 Drive LEDs location
Table 17 Drive LEDs
IndicatesStatusAppearanceLED Function
Drive failed and ready for replacementOnAmberFault1
The locatecage command is issued,
which flashes all drive fault LEDs for up
Flashing
to 15 minutes. (The I/O module Fault
LEDs at the rear of the enclosure also
flash). Fault LEDs for failed drives do not
flash.
Normal operationOnGreenStatus2
ActivityFlashing
