6. Install the PDU and ensure that the mounting pins are engaged with the rack.
Figure 44 Engage mounting pins
CAUTION: When moving a rack with installed components, always use the shipping
bracket to secure the PDU.
7. If the PDU is not inverted, install the shipping bracket above the PDU.
Figure 45 Shipping bracket installation—PDU not inverted
Installing PDUs 49
