Parts Information
Field Replaceable Parts List
Appendix A
137
PCA, QuickFind Diagnostic Board (includes plastic cover
and label)
A6961-60009 A6961-67009 n/a
PCA, QuickFind Diagnostic Board (includes plastic cover
and label) - (RoHS)
A6961-60109 A6961-67109 n/a
PCA, Power Distribution Board A6961-60015 A6961-67015 n/a
PCA, Power Distribution Board - (RoHS) A6961-60115 A6961-67115 n/a
PCA, I/O Board to DVD connectivity (IDE/USB) A6961-60113 A6961-67113 n/a
PCA, I/O Board to DVD connectivity (IDE/USB) - (RoHS) A6961-60213 A6961-67213 n/a
Memory
256 MB DIMM A6967AX A6967AX n/a
512 MB DIMM A6968AX A6968AX n/a
1 GB DIMM A6969AX A6969AX A6969-69001
2 GB DIMM A6970AX A6970AX A6835-69001
4 GB DIMM AB475AX AD041A AB475-69001
Internal disks/removable media
36 GB 15K RPM SCSI Disk (A6981A) AB420-2101A AB420-2101A AB420-69001
73 GB 15K RPM SCSI Disk (A6983A) AB421-2101A AB421-2101A AB421-69001
146 GB 10K RPM SCSI Disk (A6984A) AB422-2101A AB422-2101A AB422-69001
300 GB 10K RPM SCSI Disk (A6984A) AB423-2101A AB423-2101A AB423-69001
DVD-R/CD-R Drive A7163-2100A A7163-67002 n/a
DVD-R/CD-RW Drive AB349-2100A AB349-67101 n/a
Fans
I/O Fan A6961-04055 A6961-04055 n/a
Power Supply Fan A6961-04028 A6961-04028 n/a
Processors
Montecito CPU Assembly (1.6 GHz), 18 Mb cache AD139AX AD139A-67001 AD139-69001
Montecito CPU Assembly (1.6 GHz), 24 Mb cache AD268AX AD268A-67001 AD268-69001
Cable
Cable, Internal SCSI A6961-63006 A6961-63006 n/a
Cable, QuickFind Diagnostic to Midplane A6961-63005 A6961-63005 n/a
Table A-1 Parts List (Continued)
Description
Mfg. Part
Number
Part Number
Replacement
Part Number
Exchange
To Next Page
