Removal and Replacement Procedures
Compaq ProLiant DL380 Generation2 Server Maintenance and Service Guide 2-51
COMPAQ CONFIDENTIAL Codename: Magna Part Number: 203840-003 Last Saved On: 1/28/02 1:12 PM
12. Insert the processor  .
13. Close the locking lever on the processor socket
 .
1
2
Figure 2-46: Installing the processor
CAUTION: Always use a new heatsink with thermal interface material when replacing
processors. Failure to use new components may result in damage to the processor.
14. Remove the plastic cover on a new, unused heatsink to expose the thermal interface
material.
Figure 2-47: Removing the plastic strip on the heatsink

HP ProLiant DL380 - G2 Server Specifications

General

Form Factor	2U Rackmount
CPU	Intel Pentium III or Xeon
Storage	Up to 6 hot-plug SCSI drives
Network Controller	Integrated 10/100TX Ethernet
Power Supply	Dual redundant hot-plug
Expansion Slots	6 PCI (4x 64-bit, 2x 32-bit)
