124
Figure 38 Portal system components
Authentication client
An authentication client is a Web browser that runs HTTP/HTTPS or a user host that runs a portal
client application. Security check for the user host is implemented through the interaction between
the portal client and the security policy server.
Access device
An access device refers to a broadband access device such as a switch or a router. An access
device has the following functions:
• Redirects all HTTP requests of unauthenticated users to the portal Web server.
• Interacts with the portal authentication server and the AAA server to complete authentication,
authorization, and accounting.
• Allows users that pass portal authentication to access authorized Internet resources.
Portal authentication server
The portal authentication server receives authentication requests from authentication clients and
interacts with the access device to authenticate users.
Portal Web server
The portal Web server pushes the Web authentication page to authentication clients and forwards
user authentication information (username and password) to the portal authentication server. The
access device also redirects HTTP requests from unauthenticated users to the portal Web server.
The portal Web server can be integrated with the portal authentication server or an independent
server.
AAA server
The AAA server interacts with the access device to implement authentication, authorization,
accounting for portal users. Now only a RADIUS server can act as an AAA server in a portal system.
Security policy server
The security policy server interacts with the portal client and the access device for security check and
authorization for users.
Authentication client
Authentication client
Authentication client
Security policy
server
Portal authentication
server
Access device
Portal Web server
AAA server
