Huawei AR1200 Series Configuration Guide

[Huawei-Tunnel0/0/0] ip address 172.16.1.1 255.255.255.0
[Huawei-Tunnel0/0/0] tunnel-protocol gre p2mp
[Huawei-Tunnel0/0/0] source ethernet 1/0/0
[Huawei-Tunnel0/0/0] nhrp redirect
[Huawei-Tunnel0/0/0] nhrp entry multicast dynamic
# Configure a tunnel interface and an NHRP mapping entry of the hub, and enable NHRP shortcut
on Spoke1.
[Huawei] system-view
[Huawei] interface tunnel 0/0/0
[Huawei-Tunnel0/0/0] ip address 172.16.1.101 255.255.255.0
[Huawei-Tunnel0/0/0] tunnel-protocol gre p2mp
[Huawei-Tunnel0/0/0] source ethernet 1/0/0
[Huawei-Tunnel0/0/0] nhrp shortcut
[Huawei-Tunnel0/0/0] nhrp entry 172.16.1.1 44.1.1.1 register
# Configure a tunnel interface and an NHRP mapping entry of the hub, and enable NHRP shortcut
on Spoke2.
[Huawei] system-view
[Huawei] interface tunnel 0/0/0
[Huawei-Tunnel0/0/0] ip address 172.16.1.102 255.255.255.0
[Huawei-Tunnel0/0/0] tunnel-protocol gre p2mp
[Huawei-Tunnel0/0/0] source ethernet 1/0/0
[Huawei-Tunnel0/0/0] nhrp shortcut
[Huawei-Tunnel0/0/0] nhrp entry 172.16.1.1 44.1.1.1 register
Step 5 Verify the configuration.
After the preceding configurations are complete, check the NHRP mapping entries on Spoke1
and Spoke2.
Run the display nhrp peer all command on Spoke1, and the command output is as follows.
[Huawei] display nhrp peer all
-------------------------------------------------------------------------------
Protocol-addr Mask NBMA-addr NextHop-addr Type Flag
-------------------------------------------------------------------------------
172.16.1.1 32 44.1.1.1 172.16.1.1 static hub
-------------------------------------------------------------------------------
Tunnel interface: Tunnel0/0/0
Created time : 2011.08.18-15:10:26
Expire time : --
Run the display nhrp peer all command on Spoke2, and the command output is as follows.
[Huawei] display nhrp peer all
-------------------------------------------------------------------------------
Protocol-addr Mask NBMA-addr NextHop-addr Type Flag
-------------------------------------------------------------------------------
172.16.1.1 32 44.1.1.1 172.16.1.1 static hub
-------------------------------------------------------------------------------
Tunnel interface: Tunnel0/0/0
Created time : 2011.08.18-15:12:53
Expire time : --
NOTE
If you run the display nhrp peer all command on Spoke1 and Spoke2, you can view only the NHRP
mapping entry of the hub.
On the hub, check the NHRP mapping entries on Spoke1 and Spoke2.
Run the display nhrp peer all command on the hub, and the command output is as follows.
[Huawei] display nhrp peer all
-------------------------------------------------------------------------------
Protocol-addr Mask NBMA-addr NextHop-addr Type Flag
-------------------------------------------------------------------------------
172.16.1.101 32 44.3.1.2 172.16.1.101 dynamic route tunnel
Huawei AR1200 Series Enterprise Routers
Configuration Guide - VPN 6 DSVPN Configuration
Issue 01 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
360
