The cabinet front door is made of glass. Pay attention to the following during
transportation:
● Move the cabinet with caution.
● Ensure that the glass door does not collide with sharp objects.
● Place the glass door stably and reliably.
Procedure
Step 1 Open the front and rear doors of the cabinet.
Step 2 (Optional) Cut
o the cable tie on the PAD cable in the Converged Cabinet, and
pull the cable into the cabinet through the front door.
Record the PAD cable route because you need to bind the PAD cable along the
original route in subsequent installation.
Figure 4-17 Removing the PAD cable
Step 3 Loosen the gas spring nuts using an adjustable wrench and remove the gas
springs.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 107
