Huawei FusionModule800 User Manual

No. Check That Check Result
5 Routed cables should be convenient for future
maintenance and expansion.
□ Passed □ Failed
6 All labels at the cable ends are clear. □ Passed □ Failed
7 The excess section of a cable strip is cut evenly. □ Passed □ Failed
8 There are no unnecessary adhesive tape or cable
ties on cables.
□ Passed □ Failed
Electrical Installation Check
Table 4-20 Electric installation check items
No. Check That Check Result
1 All ground cables are copper cables. Cable
diameters are correct. No switches or fuses are
installed on the cables and no short circuit occurs.
□ Passed □ Failed
2 The ground cable, AC power cables, and internal
cables are correctly connected and screws are
secured. No short circuit occurs during power
input or output.
□ Passed □ Failed
3 The smart cooling product input voltage is within
the range of rated voltage ±10%, and the input
frequency is within the range of rated frequency
±3 Hz.
□ Passed □ Failed
4 The length of ground cables and power cables is
correct.
□ Passed □ Failed
5 Lugs for power cables and PGND cables are
soldered or crimped securely.
□ Passed □ Failed
6 Power cables and PGND cables are routed and
bundled separately from other cables.
□ Passed □ Failed
7 Lithium batteries are intact, free from damage,
cracks, and bulges.
□ Passed □ Failed
8 Lithium batteries are neat and clean, and do not
leak electrolyte.
□ Passed □ Failed
9 Lithium battery terminals are upright and free
from damage, break, and acid leakage.
□ Passed □ Failed
10 Lithium battery safety valves are intact and
without leakages.
□ Passed □ Failed
11 Lithium battery cables are connected correctly. □ Passed □ Failed
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 248
