Scenarios
Install the chassis cover after replacing parts for the N2000H V3.
Prerequisites
Conditions
You have removed the N2000H V3 from the rack and the components in the chassis are
replaced. For details, see 2.5 Removing the N2000H V3.
Data

You have obtained the rack number and chassis number of the N2000H V3.

You have located the N2000H V3 based on the preceding information, and labeled its
panel to prevent misoperations.
Tools

ESD gloves

Flat-head screwdriver
Procedure
Step 1 Place the chassis cover horizontally, align it with the fixing slots on both side panels of the
chassis, and close the handle. See steps (1) and (2) in Figure 5-16.
Step 2 Tighten the latch using a flat-head screwdriver to secure the handle. See step (3) in Figure
5-16.
