N2000H V3 Appliance
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
The rear hard disk module supports the following configurations:
Two 3.5-inch hard disk slots
I/O module
2
(correspond
ing to CPU
2)
I/O module 2 supports the following configurations:
Two 3.5-inch hard disk slots
The N2000H V3 uses two AC hot-swappable PSUs in 1+1
redundancy mode based on the input power:
AC PSUs: 110 V or 220 V
High-voltage (HV) DC PSUs: 240 V or 380 V
NOTICE
All the PSUs support double-pole/neutral fusing.
The N2000H V3 supports one GE NIC with four GE ports. Both
NICs support the Network Controller Sideband Interface (NC-SI).
PCIe card
on the
mainboard
The N2000H V3 provides two half-height half-length PCIe 3.0 x8
slots for standard PCIe cards.
The N2000H V3 supports the LSISAS3108 controller card, which
support multiple RAID levels, RAID level migration, and RAID
configuration memory. The supported RAID controller cards are
described as follows:
LSISAS3108 (SR430C, 2 GB):
− Supports RAID 0, 1, 10, 5, 50, 6, and 60.
− Provides a supercapacitor for power-off protection.
− Supports a maximum of 32 hard disks.
LSISAS3108 (SR630C, 1 GB/2 GB):
− Supports RAID 0, 1, 10, 5, 50, 6, and 60.
− Provides a supercapacitor for power-off protection.
− Supports 40 hard disks.
NOTE
When you configure dual SAS adapters or SAS RAID controller cards for the
Appliance, one of them must be a standard PCIe SAS adapter or SAS RAID
controller card.
The trusted platform module (TPM) complies with the Trusted
Computing Group (TCG) standards and protects the platform from
viruses or unauthorized operations.
The Appliance in dual-CPU configuration supports up to 16
DDR4 RDIMMs or LRDIMMs, which provide a maximum
memory capacity of 192 GB.
The Appliance in single-CPU configuration supports up to 8
DDR4 RDIMMs or LRDIMMs, which provide a maximum
