Huawei N2000H V3 - 9.4 Logging In to the Remote Virtual Console; 10 Upgrading Firmware; 10.1 Upgrading Firmware

N2000H V3 Appliance
User Guide
9 Common Operations
Issue 04 (2018-11-06)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
253
Scenarios
Log in to the iBMC WebUI, open the Remote Control page. Then log in to Appliance in
remote control mode, and monitor and operate the Appliance.
Prerequisites
Conditions
No special condition is required for this operation.
Data
The following data is available:

You have obtained the IP address for the N2000H V3 iBMC management network port.

You have obtained the user name and password for logging in to the iBMC.
The default user name is root, and the default password is Huawei12#$.
Procedure
Step 1 Log in to the iBMC WebUI.
For details, see 7.2 Logging In to the iBMC WebUI.
Step 2 In the navigation tree, choose Remote. The Remote page is displayed, as shown in Figure
7-5.
Figure 9-5 Remote page
Step 3 Click Remote Virtual Console. The real-time operation console user interface (UI) is
displayed, as shown in Figure 7-6.

Remote Virtual Console (Shared Mode): allows two users to access and operate the Appliance
simultaneously. One user can view the operations performed by the other user.

Remote Virtual Console (Private Mode): allows only one user to access and operate the
Appliance.
