NetCol5000-C Chilled Water-Cooled In-Row Precision
Air Conditioner
User Manual
2 Product Description
Issue 02 (2013-12-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
Item
Performance Specifications
7°C
temperature
rise
Cooling capacity
(kW)
24.92
20.85
18.18
14.07
8.55
Sensible cooling
capacity (kW)
24.92
20.85
18.18
14.07
8.55
Water supply
(m
3
/h)
3.10
2.56
2.23
1.72
1.05
Chilled Water Drop Curve
Figure 2-9 Curve between the pressure drop and water flow
Air Volume Curve
Figure 2-10 Curve between the air volume and fan output
Test environment: The ambient temperature is 25°C.
