Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
4 NE40E-X3 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
96
Indicat
or
Color
Statu
s
Description
Measures
The rectifier is
hibernated.
No measure is required.
Blinki
ng at
0.5 Hz
The rectifier
communication
is interrupted.
Replace the rectifier or monitoring
module.
Fault
indicato
r
Red
Off
The rectifier is
not faulty.
No measure is required.
Stead
y on
The rectifier is locked
due to output
overvoltage.
Pull out the rectifier and reinsert it
after 1 minute.
There is no output
because the rectifier is
faulty.
Replace the rectifier.
The AC power module provides the following functions:

Protection against overvoltage of input power

Protection against undervoltage of input power

Protection against overvoltage of output power

Protection against current-limiting of output power

Protection against short circuit

Protection against overtemperature
Table 4-6 lists the technical parameters of the AC power module.
Table 4-6 Technical parameters of the AC power supply module
Item
Technical Parameter
Dimensions (width x depth
x height)
40.8 mm x 105 mm x 281 mm (1.61 in. x 4.13 in. x 11.06
in.)
Weight
About 1.8 kg (3.97 lb)
Input voltage range
85 V AC ~ 300 V AC
Input current
< 17 A
Output voltage
43.2 ~ 58 V DC
Default voltage: 53.5 V DC
Maximum output current
51 A
Maximum output power
2200 W
