Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
175
Indicator
Description
OFL indicator (red)
If the indicator is on, you can remove the board safely.
RUN indicator
(green)
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state. If the indicator blinks twice every 1s (2 Hz), the
FPIC is in the alarm state.
Technical Specifications
Table 6-6 lists the technical specifications of the VSUF-10.
Table 6-6 Technical specifications of the VSUF-10
Item
Specifications
Dimensions (width
x depth x height)
399 mm x 551 mm x 41 mm ( 15.71 in. x 21.69 in. x 1.61 in. )
Power consumption
(typical value)
About 150 W
Heat dissipation
487 BTU/hour
Board weight
About 5.3kg ( 11.69 lb )
Product Specifications
Table 6-7 lists the product specifications of the VSUF-10.
Table 6-7 Product specifications of the VSUF-10
Item
Specifications
Reliability and
availability
Software features

FCC

RET

MDI
Hardware features

Supporting hot swap
NMS
Enhanced command-line interface
SNMP and MIB support
Operating
conditions
Long-term ambient temperature: 0°C to 45°C ( 32°F to 113°F )
Short-term ambient temperature- -5°C to +55°C ( 23°F to 131°F )
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 0% to 95%
