HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Panel
Table 6-32 lists the indicators on the panel.
Table 6-32 Indicators on the panel of the 24-Port 100/1000Base-SFP FPIC
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state. If the indicator blinks twice every 1s (2 Hz), the
FPIC is in the alarm state.
LINK/ACT
indicator(green)
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-33 lists the interface attributes of the 24-Port 100/1000Base-SFP FPIC.
Table 6-33 Interface attributes of the 24-Port 100/1000Base-SFP FPIC
Optical interface
attributes
Compliant with the selected SFP optical module. For the attributes
of SFP modules, see Table 6-34 and Table 6-35.
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Table 6-34 Attributes of 100M SFP optical modules
Minimum
transmitting power
Maximum
transmitting power
