Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
211
Attributes
Description
transmitting
power
Maximum
transmitting
power
-1.3 dBm
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-7.5 dBm
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload
power
-1.0 dBm
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical transceiver supports two types of multi-mode optical fibers
with different cores. Table 6-63 lists the relationship between the core, the modal/bandwidth,
and the transmission distance. During configuration, the length of optical fibers is restricted
by the transmission distance. In addition, the optical fiber with the 50-um core and
2000-MHz*km modal/bandwidth is a special type, If this type of optical fibers are required,
you need to purchase it additionally.
Table 6-63 The transmission distance of 10G XFP optical modules
Core Fiber(μm)
Modal/Bandwidth(Mhz*
km)
Transmission
distance(km)
50
2000
2 ~300 ( 1.24 ~ 186.42 )
50
500
2 ~82 ( 1.24 ~ 50.95 )
62.5
200
2 ~33 ( 1.24 ~ 20.51 )
Technical Specifications
Table 6-64 lists the technical specifications of the 10-Port 10GBase LAN/WAN-XFP
Integrated Line Processing Unit.
Table 6-64 Technical specifications of the 10-Port 10GBase LAN/WAN-XFP Integrated Line
Processing Unit
Item
Specifications
Silkscreen
of the
board
name
LPUI-100
10x10GBase LAN/WAN-XFP-1588v2
Power
consumpti
on(Typica
About 366 W
