Table 6-81 Indicators on the panel of the 16-Port 10GBase LAN-SFP+ Line Processing Unit S
Component
Description
OFL button
It is an OFL button. Before removing a board, press the OFL button.
Hold the button for six seconds till the OFL indicator is on. Then, the
board can be pulled out.
OFL indicator
(red)
If the indicator is steady on, it indicates that you can remove the
board.
RUN (green)
If the indicator blinks once every 2s (0.5 Hz), it indicates that the
system is running normally. If the indicator blinks twice every 1s (2
Hz), it indicates that the system is in the alarm state.
L/A (green)
If the indicator is steady on, it indicates that the link is normal. If the
indicator blinks, it indicates that data is being transmitted. If the
indicator is off, it indicates that the link is Down.
Interface Attributes
Table 6-82 lists the interface attributes of the 16-Port 10GBase LAN-SFP+ Line Processing
Unit S.
Table 6-82 Interface attributes of the 16-Port 10GBase LAN-SFP+ Line Processing Unit S
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected XFP optical module.
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-83 Attributes of 10G SFP+ optical modules
Attributes
Description
Maximum
transmission
distance
0.3 km ( 0.19 mi. )
10 km ( 6.21 mi. )
40 km ( 24.86 mi. )
Center
wavelength
850 nm
1310 nm
1550 nm
Minimum
transmitting
-7.3 dBm
-8.2 dBm
-4.7 dBm

Huawei NetEngine40E Specifications

General

Brand	Huawei
Model	NetEngine40E
Category	Network Router
Language	English
