Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
235
Attributes
Description
Overload power
0 dBm
-3.0 dBm
-3.0 dBm
-3.0 dBm
-3.0
dBm
-9.0 dBm
Optical fiber type
Multi-mo
de
Single-m
ode
Single-m
ode
Single-m
ode
Single-
mode
Single-m
ode
Technical Specifications
Table 6-97 lists the technical specifications of the 24-Port 100/1000Base-X-SFP Flexible Card
A.
Table 6-97 Technical specifications of the 24-Port 100/1000Base-X-SFP Flexible Card A
Item
Specifications
Silk screen of the board
name
P101-24×FE/GE-SFP-A
Power consumption(Typical
value)
About 37 W
Heat dissipation
120.04 BTU/hour
Board weight
About 1 kg ( 2.21 lb )
Dimensions (width x depth
x height)
178mm x 180mm x 38mm ( 7.01 in. x 7.09 in. x 1.50 in. )
Connector type
LC
Lowest Software Version
V600R006C00
Product Specifications
Table 6-98 lists the product specifications of the 24-Port 100/1000Base-X-SFP Flexible Card
A.
Table 6-98 Product specifications of the 24-Port 100/1000Base-X-SFP Flexible Card A.
Item
Specifications
Supported protocol
and service
Ethernet_II
Ethernet_SAP
Ethernet_SNAP
Interface type
SFP
RJ-45
Reliability and
availability
Supporting hot swap
