Table 6-124 Indicators on the panel of the 2-Port 40GBase LAN-CFP Integrated Line Processing
Unit B
Component
Description
OFL button
It is an OFL button. Before removing a board, press the OFL button.
Hold the button for six seconds till the OFL indicator is on. Then, the
board can be pulled out.
OFL indicator
(red)
If the indicator is steady on, it indicates that you can remove the
board.
RUN (green)
If the indicator blinks once every 2s (0.5 Hz), it indicates that the
system is running normally. Otherwise, it indicates that the board fails
to run normally.
LINK/ACT
(green)
If the indicator is steady on, it indicates that the link is normal. If the
indicator blinks, it indicates that data is being transmitted. If the
indicator is off, it indicates that the link is Down.
Interface Attributes
Table 6-125 lists the interface attributes of the 2-Port 40GBase LAN-CFP Integrated Line
Processing Unit B.
Table 6-125 Interface attributes of the 2-Port 40GBase LAN-CFP Integrated Line Processing Unit
B
Attributes
Description
Connector type
LC
Optical
interface
attributes
Compliant with the selected CFP optical module.
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-126 Attributes of 40G CFP optical modules
Attributes
Description
Transmission distance
10 km (6.21 mi)
Center wavelength
1310 nm
Minimum transmitting power
-4 dBm
Maximum transmitting power
3.5 dBm
