Indicator/Butto
n
Description
(green)
indicator blinks, it indicates that data is being transmitted. If the
indicator is off, it indicates that the link is Down.
Interface Attributes
Table 6-140 lists the interface attributes of the 1-Port 100GBase-CFP Line Processing Unit S.
Table 6-140 Interface attributes of the 1-Port 100GBase-CFP Line Processing Unit S
Attribute
Description
Connector type
SC/LC
Optical
interface
attributes
Compliant with the selected CFP optical module. (For the attributes of
CFP modules, see Table 6-141)
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-141 Attributes of 100G CFPoptical modules
Attributes
Description
Transmission distance
10 km ( 6.21 mi. )
10 km ( 6.21 mi. )
Center wavelength
1310 nm
1550 nm
Minimum transmitting
power
-4.3 dBm
-2.8 dBm
Maximum transmitting
power
4.5 dBm
3.5 dBm
Receiving sensitivity
-8.6 dBm
-8.8 dBm
Overload power
4.5 dBm
3.5 dBm
Optical fiber type
Single-mode
Single-mode
Technical Specifications
Table 6-142 lists technical specifications of the 1-Port 100GBase-CFP Line Processing Unit
S.
